Solving TaC Coating Peeling on Rings Used in LPE Epitaxy Systems

Many LPE chip manufacturing machines utilize TaC coated rings. This coating helps maintain a stable, clean environment within the machine. As the coating wears, Cvd sic coating or chips off, tiny fragments can enter the machine, contaminating wafers and lowering the quality of the finished product.

TaC coating and Cvd sic damage doesn't occur instantaneously but develops over a large number of cycles including heating, cooling, and cleaning cycles. In a normal maintenance, workers may find that the surfaces of some parts are no longer smooth, there is micro-cracking, or chunks are flaking off the edges. Knowing the reasons behind this wear could significantly lengthen the lifetime of machine parts.

Root Causes of Edge Cracking in CVD TaC Coated Graphite Rings

Typically edge cracks start as small flaws that develop over time, then the coating starts to peel.

Thermal stress is one of the primary reasons. CVD TaC and graphite expand and contract at different rates as they are heated and cooled, causing a strain between the two materials every time they heat up or cool down. The weakest parts of the coating are often on the edges, so this is where cracks often begin to form.

Rapid heating and cooling exacerate thermal stress problems. Machines that undertake multiple runs with insufficient cooling time apply an immense amount of stress on the coated rings, and small edge cracks develop and then get larger after each run.

Cleaning can also lead to early failure of the coating. Aggressive cleaning with harsh chemicals, or plasma cleaning will damage the binding between the TaC coating and graphite substrate, eventually weakening the edges and causing a crack to form.

Poor handling is a common reason for damage. A small impact during the transportation or installation of the rings can introduce tiny weak spots on the edges that cannot be seen, which can develop into cracks during heating/cooling.

The quality of the graphite substrate also contributes to cracking. Small holes in the graphite, or irregular density will affect the way the coating sticks, and create stress points, which will lead to the coating to chip.

In most cases, a combination of more than one of the above will occur.

Thermal Expansion Mismatch in LPE (ASM) Epitaxial Parts

Another main cause of coating failure is know as thermal expansion mismatch. This is really a very simple concept and that is the TaC coating and graphite have different amounts that they expand and contract by when the temperature changes.

As the temperature increases, the graphite expands more then the TaC coating can allow to happen. Therefore there is stresses build up in the material as the coating will not elongate to accommodate this extra size and then as the temperature decreases the graphite contracts by more then the coating will. This again causes stresses in the material.

After hundreds of thermal cycles and High purity CVD SiC raw material the stresses built up in the two materials break down the bond that holds the coating and substrate together and the coating starts to chip, crack, or delaminate. Sharp corners and edges tend to have the greatest stresses and fail the earliest.

The production team for example had coated rings which were cracking at half their usual lifespan; when checked the process they realized that they were cooling the rings to quickly. By altering the cooling procedure their lifespan increased significantly.

The thickness and shape of the coating also play an important role in terms of the stresses built up in the material; thickness and a non uniform surface design create increased stress development.

Due to this factors a repeatable heating and cooling cycle and good coating quality is necessary to ensure that the component fails.

How Coating Thickness Influences TaC Coating Peeling Risks

The thickness of the TaC coating has a large impact on part lifetime. Thin coatings are not sufficient to protect the graphite from heat and chemicals. Over time pits and defects develop until the coating peels away from the substrate. Thick coatings have high amounts of stored stress.

Repeated heating and cooling cycles will tend to delaminate the coating from the substrate, typically near corners and edges. The variation in thickness, however, is as critical as the average thickness.

An even coating with slightly higher than expected thickness is much better than an uneven coating that happens to be near the target average thickness, because stresses are not equally distributed.

Generally the best coating will be well-adhered and of average thickness with small variation.

Repair Strategies for Damaged CVD TaC Coated Epitaxy Components

Damaged parts do not always need to be replaced immediately. Depending on the level of damage, replacement of the graphite or the coating may not be necessary.

If the graphite is not severely damaged then the old coating may be removed from the part, a new TaC coating can be deposited (re-coating).

The damaged areas only may be repaired if the damage is localized. This would mean the coating in these areas only would be removed and re-deposited. This would allow the life of the part to be extended although typically this method is only an intermediate solution.

Additional material can be deposited at locations of high wear (e.g. Edges) as these points of the part are most prone to failure. This allows the edges of the part to be reinforced without over-coating the part as a whole.

However, this method is not always suitable. It is generally advisable to replace severely damaged graphite with new parts if the graphite is badly damaged, or if there are numerous layers of coating on the part and thus has been repaired several times before or is contaminated with slag. Engineers should consider both the visual aspect of the damage along with a review of how the part had previously been used.

Reducing Particle Generation from Delaminated TaC Coating Surfaces

When the TaC coatings delaminate, instead of large flakes being produced, small particles tend to be emitted. These particles are free to migrate around the chamber and may settle on the wafers producing a defect.

A good technique for avoiding contamination is to detect the coating damage as soon as possible. During routine checks, workers should be looking for dull patches, tiny cracks, or slight lifting of small regions of the coating.

By replacing the part when the delamination first starts, particle generation can be avoided.

The slow thermal change maintains stress throughout your bonded layer and prevents the bond from snapping and the coating from breaking. In your cleaning station you should try to modify your cleaning procedure as your parts age, because the harsh chemicals and plasma have been observed to erode away surface materials causing a rough surface area where particles can easily break away, so try not to run all parts with aggressive cleaning settings.

During the application you need to handle the parts gently because one minor tap from a hard surface while a ring is in transit, or being pressed, will cause chips to break away at the edges and leave dust behind. You must handle with support and do not touch the edges at all costs.

Some teams also apply a light post-coating surface treatment to strengthen the outer layer. This does not change the main coating, but it can help seal micro-pores that would otherwise become particle sources during operation.

In the end, reducing particles is less about one major fix and more about steady control. Stable temperature profiles, careful cleaning, and early replacement of weak coatings all work together. Once delamination starts, the goal is not only to stop it, but also to prevent those small fragments from entering the process space where they can affect every wafer run.
